MicaSense

AgEagle RedEdge-P Dual

  • DeltaQuad Evo
Contact us for best pricing
Contact us for best pricing

Proof of concept program

Remote Robotic helps enterprise and public-sector teams validate advanced robotics solutions—drones, UGVs, ROVs, docking systems, and sensors—through a hands-on Proof-of-Concept (POC) program.

Designed for utilities, public safety, mining, energy, and large industrial organizations that need clarity, ROI, and operational certainty before investing.

Learn more and apply

DeltaQuad integration
IP4X Rated
Weight: 745 g
5.1 MP Panchromatic band
10 Multispectral bands
Multispectral sensor kit

Unlock superior spectral data for vegetation, water bodies, environment and infrastructure monitoring with the RedEdge-P Dual. This advanced payload combines two synchronized sensors to deliver 10 narrow spectral bands plus a high-resolution panchromatic output—enabling sub-2 cm GSD mapping results at altitude and seamless comparison with satellite bands (e.g., Landsat 8 / Sentinel-2) in a drone workflow. With global-shutter sensors, radiometric calibration tools and pan-sharpening technology, it’s designed for high-precision, repeatable missions in agriculture, forestry, utilities and remote operations.

Specification Sheet

  • Weight (kit): 745 g (≈ 26.2 oz) including both sensors, mounting hardware, DLS2 & cables.
  • Dimensions: 13.2 cm × 8.8 cm × 9.67 cm (5.1″ × 3.1″ × 3.5″) for the dual-sensor kit.
  • Spectral Bands: Coastal Blue 444(28), Blue 475(32), Green 531(14), Green 560(27), Red 650(16), Red 668(14), Red Edge 705(10), Red Edge 717(12), Near-IR 740(18), Near-IR 842(57) nm.
  • Sensor Resolution: 1.6 MP per multispectral band (1456 × 1088) + 5.1 MP panchromatic band (2464 × 2056) in dual kit.
  • Ground Sample Distance (GSD): 7.7 cm (≈ 3 in) per pixel at 120 m AGL for multispectral bands; pan-sharpened output ~3.98 cm per pixel.
  • Capture Rate: Up to 3 raw DNG captures per second.
  • Field of View: Multispectral band HFOV 50° × VFOV 38°; Panchromatic HFOV 44° × VFOV 38°.
  • Power Input: 7.0V–25.2V external power; typical standby/average/peak 11W/14W/20W.
  • IP Rating: IP4X (for ambient without airflow 0-40 °C; with airflow >0.5m/s up to 50 °C) per datasheet.

Remote Robotic is a North American authorized dealer for MicaSense AgEagle RedEdge-P Dual.

Your purchase includes the full standard manufacturer warranty, and we also offer optional support programs to help protect your equipment and keep it performing at its best.

Learn more about Extended Care Program

We offer training for all robotic solutions

Learn more

AgEagle RedEdge-P Dual FAQ

The Dual version pairs two sensors (RedEdge-P + Blue variant) to cover 10 narrow spectral bands (including a coastal-blue band) plus a pan-sharpened panchromatic band—enabling higher spatial resolution and richer spectral data for machine-learning, precision mapping and vegetation/water analysis.

It is compatible with a wide range of VTOL/fixed-wing UAVs (including integration with the DeltaQuad Evo series) and supports open API, CFexpress storage and standard flight-planner software.

Can the data be used for time-series analysis across multiple flights?
