AgEagle RedEdge-P

  • DeltaQuad Evo
Contact us for best pricing
Contact us for best pricing

Proof of concept program

Remote Robotic helps enterprise and public-sector teams validate advanced robotics solutions—drones, UGVs, ROVs, docking systems, and sensors—through a hands-on Proof-of-Concept (POC) program.

Designed for utilities, public safety, mining, energy, and large industrial organizations that need clarity, ROI, and operational certainty before investing.

Learn more and apply

5.1 MP Panchromatic band
IP4X Rated
Weight: ~ 350 g
5 Multispectral bands
1.6 MP Resolution per band
Multispectral + Panchromatic sensor

Achieve industry-leading multispectral imaging with the RedEdge-P. Designed for precision drone mapping and asset monitoring, it features a high-resolution panchromatic band and five narrow multispectral bands, enabling pan-sharpened resolution down to ~2 cm per pixel at 60 m altitude. Ideal for agriculture, utilities, environmental, and remote-operations mapping workflows, this sensor offers rugged calibration, global shutter performance and seamless integration into professional UAV platforms.

Specification Sheet

  • Weight: ~ 350 g (12.34 oz) including DLS 2 & cables.
  • Dimensions: 8.9 cm × 7.0 cm × 6.7 cm (3.5″ × 2.8″ × 2.6″)
  • Sensor Resolution: 1.6 MP per multispectral band (1456 × 1088) / 5.1 MP panchromatic (2464 × 2056)
  • Spectral Bands: Blue (475 nm ±32), Green (560 nm ±27), Red (668 nm ±14), Red Edge (717 nm ±12), Near-IR (842 nm ±57)
  • Ground Sample Distance (GSD): ~ 7.7 cm per pixel (multispectral band) at 120 m AGL / ~3.98 cm per pixel (panchromatic) at same altitude.
  • Capture Rate: Up to 3 raw DNG captures per second.
  • Interfaces: GPIO (trigger, PPS, top-of-frame), USB2.0 WiFi, Serial, 10/100/1000 Ethernet, CFexpress storage.
  • External Power: 7.0 V – 25.2 V
  • IP Rating: IP4X (ambient without airflow)

Remote Robotic is a North American authorized dealer for MicaSense AgEagle RedEdge-P.

Your purchase includes the full standard manufacturer warranty, and we also offer optional support programs to help protect your equipment and keep it performing at its best.

Learn more about Extended Care Program

We offer training for all robotic solutions

Learn more

AgEagle RedEdge-P FAQ

The sensor is designed for professional aerial mapping operations including agriculture, forestry, utilities and environmental monitoring. It features a rugged build, global shutter on all bands and supports pan-sharpening for high resolution.

The internal panchromatic band allows the system to produce higher spatial resolution imagery (down to ~2 cm per pixel at 60 m altitude) by combining multispectral and panchromatic data—giving sharper maps and more actionable outputs.

Yes. Its compact weight (~350 g) and interface options (CFexpress storage, Ethernet, GPIO) make it suitable for a variety of UAV platforms. You’ll still need to confirm UAV payload bay compatibility, mounting, vibration isolation, and power supply.
